UA79M08CKVURG3_TI(德州仪器)中文资料_英文资料_价格_PDF手册

2024/5/15 18:40:03

70

UA79M08CKVURG3

500mA 负电压线性稳压器





                                          更多技术详情请登录www.mroic.cn



· 3-Terminal Regulators

· Output Current Up To 500 mA

· No External Components

· High Power-Dissipation Capability

· Internal Short-Circuit Current Limiting

· Output Transistor Safe-Area Compensation











description/ordering information



This series of fixed-negative-voltage integrated-circuit voltage regulators is designed to complement the µA78M00 series in a wide range of applications. These applications include on-card regulation for elimination of noise and distribution problems associated with single-point regulation. Each of these regulators delivers up to 500 mA of output current. The internal current-limiting and thermal-shutdown features of these regulators essentially make them immune to overload. In addition to use as fixed-voltage regulators, these devices can be used with external components to obtain adjustable output voltages and currents, and also as the power-pass element in precision regulators.
